Water Proof KSD301 Bimetallic Thermostat Temperature Control Thermal Cut Off Switch 250V 10A 16A With CQC TUV UL ROHS
Product Details:
| Place of Origin: | China |
| Brand Name: | JULUN |
| Certification: | CE UL CCC |
| Model Number: | KSD301 KSD302 Bimetal Thermostat |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 |
|---|---|
| Price: | 0.7~1.5 |
| Packaging Details: | Carton |
| Delivery Time: | 1~2weeks |
| Payment Terms: | T-T |
| Supply Ability: | 1000K/times |
|
Detail Information |
|||
| Voltage & Current: | AC 125V Max 15A; AC250V 5A 10A 15A Max 16A | Contact Type: | Normally Closed Or Normally Open |
|---|---|---|---|
| ActionTemperature: | 0~250℃ | Life Cycle: | ≥100000 Times |
| Temperature Deviation:: | ±3 / ±5 / ±10 Degree Or According To Client's Request | Temperature Sensor Face: | Aluminum Cap Or Copper Head. |
| Two Kinds Of Mounting Bracket: | Movable Or Immovable | House: | Plastic Or Ceramic. |
| Highlight: | Water Proof Thermal Cut Off Switch,250V Thermal Cut Off Switch,10A Thermal Cut Off Switch |
||
Product Description
Product Description:
The sensor has a maximum voltage and current rating of AC 125V 15A and AC250V 5A 10A 15A max 16A respectively. This makes it suitable for use in a variety of electrical systems and appliances. The model name of the sensor is KSD301 KSD302, which is a threaded brass model that allows for easy installation and maintenance.
The insulation resistance of the sensor is AC50Hz 1500V / Min, with no breakdown blinding in the normal state. This ensures that the sensor can operate effectively even in high voltage environments and is safe to use. The sensor also has a recovery and action temperature difference of 0 to 25 degrees Celsius, or according to the client's request. This means that the sensor can accurately measure temperature even in extreme conditions.
The Thermistor Temperature Sensor has a long life cycle of over 100,000 times, making it a reliable and durable choice for your temperature sensing needs. It is suitable for use in a variety of applications, including incubators and hot water kettles.
With its threaded brass design and accurate temperature sensing capabilities, the Thermistor Temperature Sensor is the perfect choice for anyone in need of a reliable and efficient temperature sensing solution. Order yours today and experience the benefits of accurate temperature measurement.
Features:
- Product Name: Thermistor Temperature Sensor
- Recovery and action temperature difference: 0 To 25 Degrees, Or According To Client's Request.
- House: Plastic Or Ceramic.
- Life cycle: ≥100000 Times
- Voltage & Current: AC 125V Max 15A; AC250V 5A 10A 15A Max 16A
- Action Temperature: 0~250℃
Temperature controller
Hot Water Kettle
0~250°C
Technical Parameters:
| Model Name | KSD301/KSD302 |
| Mounting Bracket | Movable/Immovable |
| Terminal Type | A. Terminal Type: 187series Of 4.8*0.5mm And 4.8*0.8mm, 250 Series Of 6.3*0.8mm B. Terminal Angle: Bending Angle: 0~90°C Optional |
| Life Cycle | ≥100000 Times |
| Temperature Deviation | ±3 / ±5 / ±10 Degree Or According To Client's Request |
| Contact Type | Normally Closed Or Normally Open |
| Temperature Sensor Face | Aluminum Cap Or Copper Head |
| Insulation Resistance | AC50Hz 1500V / Min, No Breakdown Blinding (Normal State) |
| Circuit Resistance | ≤50mΩ (Initial Value) |
| Action Temperature | 0~250℃ |
Temperature control switch, hexagonal, 0~250°C
Applications:
The Temperature Sensor product has an aluminum cap or copper head for the temperature sensor face and can be used in various application scenarios such as a Temperature Controller, Incubator, and Threaded Brass. The product comes with two kinds of mounting brackets, movable or immovable. The product is designed to work in a wide range of temperatures and can detect temperature deviations of ±3 / ±5 / ±10 degrees or according to the client's request.
The product is versatile and can be used in different industries such as medical, industrial, and domestic applications. The Thermistor Temperature Sensor product is an ideal choice for those who are looking for a reliable and efficient temperature sensor that can be used in a variety of scenarios. With its high-quality design and certifications, the product has gained popularity among customers worldwide.
Customization:
Brand Name: JULUN
Model Number: KSD301 KSD302 Bimetal Thermostat
Place of Origin: China
Certification: CE UL CCC
Minimum Order Quantity: 100
Price: 0.7~1.5
Packaging Details: Carton
Delivery Time: 1~2 weeks
Payment Terms: T-T
Supply Ability: 1000K/times
Recovery and action temperature difference: 0 To 25 Degrees, Or According To Client's Request.
Model name: KSD301 KSD302
Insulation resistance: AC50Hz 1500V / Min, No Breakdown Blinding (Normal State)
Voltage & Current: AC 125V Max 15A; AC250V 5A 10A 15A Max 16A
Action Temperature: 0~250℃
Our thermistor temperature sensor product is perfect for household appliances and has a hexagonal shape. It has a wide range of action temperature from 0 to 250°C.
Support and Services:
Our Thermistor Temperature Sensor product comes with comprehensive technical support and services, including:
- Assistance with product installation and setup
- 24/7 technical support for any issues that may arise
- Product training and education for users
- Regular firmware and software updates to ensure optimal performance
- Repair and maintenance services, including replacement of faulty parts if necessary
- Extended warranty options for added peace of mind
Our team of experts is dedicated to ensuring that our customers have a seamless and hassle-free experience with our Thermistor Temperature Sensor product.
