M6 Bolt Type Electric Car 70VDC New Energy Vehicle Electric Vehicle Fuse 200A EV320 5C

Product Description:

Our Electric Vehicle Fuse has a temperature control range of -40 °C to 70°C, ensuring that it can operate in a wide range of temperatures. This makes it a reliable choice for all types of electric vehicles.

Our EV fuse is manufactured according to the ISO8820-5 and GB/T31465.5-2015 standards, ensuring that it meets the highest quality standards. With our EV fuse, you can be assured that your electric vehicle is protected against electrical faults and other issues.

The outer pipe material of our Electric Vehicle Fuse is made from ceramic copper, silver, gold, and quartz sand. This makes it a durable and long-lasting product that can withstand the toughest conditions.

Our Electric Vehicle Fuse is suitable for use in portable EV chargers, electric vehicle fast charging, automotive battery chargers, and more. It is a versatile product that is perfect for all your electric vehicle needs.

Invest in our Electric Vehicle Fuse today and ensure the safety and protection of your electric vehicle. With our high-quality product, you can be assured of the best performance and reliability.



Features:

• Product Name: Electric Vehicle Fuse
• Outer pipe material:
  • Ceramic
  • Copper
  • Silver
  • Gold
  • Quartz Sand
• Use for:
  • EV Traction System
  • Power Conversion
  • Energy Storage
  • Car Charger and Etc.
• Temperature control range: -40 °C～70°C
• Suitable for:
  • EV Application
  • Functions as both Overload and Short-circuit Protection
• Rated current:
  • 80A
  • 100A
  • 125A
  • 150A
  • 175A
  • 200A
  • 225A
  • 250A
  • 300A
  • 350A
  • 400A
  • 500A

Can be used with 22KW Charger, DC Electric Car Charging.



Technical Parameters:

Technical Parameter	Description
Suitable for	EV Application. Functions as both overload and short-circuit protection.
Outer pipe material	Ceramic Copper, Silver, Gold, Quartz Sand
EV fuse standard	ISO8820-5 and GB/T31465.5-2015
Breaking Capacity	DC 6kA (time constant 2±0.5ms)
Installation mode	M6 Bolt Type
Specifically designed for	Automobile Application. With excellent resistant to vibration, mechanical shock, chemical load and high temperature.
Scope of application	Automobile Application, 7KW Charger, DC Electric Car Charging, home ev charger for Electric Car.
Packing method	Boxed
Use for	EV Traction System, Power Conversion, Energy Storage, Car Charger and etc.
Rated current	80A, 100A, 125A, 150A, 175A, 200A, 225A, 250A, 300A, 350A, 400A, 500A



Applications:

With a wide range of breaking capacities available, including 80A, 100A, 125A, 150A, 175A, 200A, 225A, 250A, 300A, 350A, 400A, 450A, and 500A, and a rated voltage of 70VDC, this electric vehicle fuse is versatile enough to work with a variety of different charging systems.

Whether you're using a 22KW charger, a 7KW charger, or a DC electric car charging system, you can trust the EV320-5X to protect your vehicle's electrical system from damage and ensure a safe and reliable charging experience.

With a minimum order quantity of 100 and a price range of 1.5~2.8USD, this electric vehicle fuse is an affordable and accessible option for both individual consumers and businesses alike. And with a supply ability of 1000K/PCS and a delivery time of 1-2 weeks, you can rest assured that you'll receive your order in a timely and efficient manner.

Installation is made easy thanks to the M6 bolt type installation mode, and the temperature control range of -40°C to 70°C ensures that this fuse can withstand even the harshest environments and conditions.

So if you're looking for a reliable and high-quality electric vehicle fuse for your automobile application, look no further than SINOFUSE's EV320-5X series.



Customization:



Support and Services:

Our Electric Vehicle Fuse product is designed to provide protection in high voltage electric vehicle systems. Our technical support team is available to assist with any questions or issues related to the installation or use of our product. We also offer a range of services, including testing and analysis of electric vehicle systems to ensure optimal performance and safety. Contact us for more information on our technical support and services.



Packing and Shipping:

Product Packaging:

• 1 Electric Vehicle Fuse
• Instruction Manual
• Protective Packaging

Shipping Information:

• Weight: 0.5 lbs
• Dimensions: 5 x 3 x 1 inches
• Shipping Method: Standard Ground
• Shipping Cost: $5.99



FAQ:

A: The brand name of the Electric Vehicle Fuse is SINOFUSE.

Q: Where is the Electric Vehicle Fuse manufactured?

A: The Electric Vehicle Fuse is manufactured in China.

Q: What certifications does the Electric Vehicle Fuse have?

A: The Electric Vehicle Fuse has CE, UL, and CCC certifications.

Q: What is the minimum order quantity for the Electric Vehicle Fuse?

A: The minimum order quantity for the Electric Vehicle Fuse is 100.

Q: What is the price range for the Electric Vehicle Fuse?

A: The price range for the Electric Vehicle Fuse is between 1.5 to 2.8 USD.

Q: What is the delivery time for the Electric Vehicle Fuse?

A: The delivery time for the Electric Vehicle Fuse is 1-2 weeks.

Q: What are the payment terms for the Electric Vehicle Fuse?

A: The payment terms for the Electric Vehicle Fuse are T-T.

Q: What is the supply ability of the Electric Vehicle Fuse?

A: The supply ability of the Electric Vehicle Fuse is 1000K/PCS.

Q: What are the available models and specifications for the Electric Vehicle Fuse?

A: The available models and specifications for the Electric Vehicle Fuse are EV320-5X 5C 80A 100A 125A 150A 175A 200A 225A 250A 300A 350A 400A 450A 500A 70VDC.

Q: What is the packaging detail for the Electric Vehicle Fuse?

A: The packaging detail for the Electric Vehicle Fuse is carton.
